Programmation : fonctions spéciales
10.2
Usiner avec les axes parallèles U, V et W
10
334
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
Déplacer l'axe principal et l'axe parallèle simultanément
Si la fonction
PARAXMODE est active, la TNC exécute les
déplacements programmés dans les axes définis avec ladite fonction.
Si la TNC doit déplacer simultanément un axe parallèle et son axe
principal associé, vous pouvez introduire cet axe en plus avec le signe
"
&". L'axe avec le caractère & se réfère alors à l'axe principal.
L'élément de syntaxe "
&" n'est autorisé que dans les
séquences L.
Le positionnement supplémentaire d'un axe principal
avec l'instruction "
&" est assuré dans le système
REF. Si l'affichage de position est réglée sur „valeur
effective“, ce déplacement ne sera pas affiché.
Commuter l'affichage de position sur „valeur REF“ si
nécessaire
Séquence CN
13 FUNCTION PARAXMODE X Y W
14 L Z+100 &Z+150 R0 FMAX
FONCTION PARAXMODE OFF
Le fonctionnement des axes parallèles est désactivé par la fonction
PARAXCOMP OFF. La TNC utilise les axes principaux configurés par le
constructeur de la machine. Pour la définition, procédez de la manière
suivante :
Afficher la barre de softkeys avec les fonctions
spéciales
Choisir le menu de définition des diverses fonctions
Texte clair
Choisir
FONCTION PARAX
Choisir
FONCTION PARAXMODE
CHOISIR FUNCTION PARAXMODE OFF
Séquence CN
13 FUNCTION PARAXCOMP OFF
