Tableaux et résumés
16.4 Tableaux récapitulatifs
16
510
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
Numéro
de cycle
Désignation du cycle
Actif
DEF
Actif
CALL
241
Perçage monolèvre
■
247
Initialisation du point d'origine
■
251
Poche rectangulaire, usinage intégral
■
252
Poche circulaire, usinage intégral
■
253
Rainurage
■
254
Rainure circulaire
■
256
Tenon rectangulaire, usinage intégral
■
257
Tenon circulaire, usinage intégral
■
262
Fraisage de filets
■
263
Filetage sur un tour avec chanfrein
■
264
Filetage avec perçage
■
265
Filetage hélicoïdal avec perçage
■
267
Filetage externe sur tenons
■
Fonctions auxiliaires
M
Effet
Action sur séquence
au début
à la fin
Page
M0
ARRET exécution du programme/ARRET broche/ARRET arrosage
■
M1
ARRET exécution du programme/ARRET broche/ARRET arrosage
■
M2
ARRET exécution du programme/ARRET broche/ARRET arrosage
Effacer l'affichage d'état (dépend du paramètre machine)/saut à
la séquence 1
■
M3
M4
M5
Broche MARCHE dans le sens horaire
Broche MARCHE dans le sens anti-horaire
ARRET Broche
■
■
■
M6
Changement d'outil/ARRET exécution du programme (en
fonction du paramètre machine)/ARRET broche
■
M8
M9
MACHE Arrosage
ARRET Arrosage
■
■
M13
M14
Broche MARCHE dans le sens horaire/MARCHE Arrosage
Broche MARCHE dans le sens anti-horaire/MARCHE Arrosage
■
■
M30
Fonction dito M2
■
M89
Fonction auxiliaire libre
ou
appel de cycle, effet modal (en fonction du paramètre machine)
■
■
Manuel
d'utilisation
des
cycles
M91
Dans la séquence de positionnement : les coordonnées se
réfèrent au point zéro machine
■
M92
Dans la séquence de positionnement : les coordonnées se
réfèrent à une position définie par le constructeur de la machine,
par exemple à la position de changement d'outil
■
M94
Réduction de l'affichage de position angulaire à une valeur
inférieure à 360°
■
M97
Usinage de petits éléments de contour
■
