5 contournage : coordonnées polaires, Sommaire, Contournage : coordonnées polaires – HEIDENHAIN TNC 320 (34055x-06) Manuel d'utilisation
Page 196
Programmation : programmer les contours
6.5
Contournage : coordonnées polaires
6
196
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
6.5
Contournage : coordonnées polaires
Sommaire
Les coordonnées polaires vous permettent de définir une position
par un angle
PA et une distance PR par rapport à un pôle CC défini
précédemment.
L'utilisation des coordonnées polaires est intéressante pour :
les positions sur des arcs de cercle
les plans avec données angulaires (ex. cercles de trous)
Résumé des fonctions de contournage avec coordonnées polaires
Fonction
Touche de
contournage
Mouvement d'outil
Introductions requises
Page
Droite
LP
+
Droite
Rayon polaire, angle
polaire du point final de la
droite
Arc de cercle
CP
+
Trajectoire circulaire avec
point final et centre de
cercle/pôle
Angle polaire du point
final du cercle, sens de
rotation
Arc de cercle
CTP
+
Trajectoire circulaire avec
raccordement tangentiel
à l'élément de contour
précédent
Rayon polaire, angle
polaire du point final du
cercle
Trajectoire
hélicoïdale (hélice)
+
Superposition d'une
trajectoire circulaire et
d'une droite
Rayon polaire, angle
polaire du point final du
cercle, coordonnée du
point final dans l'axe
d’outil
