Résumé des fonctions DIN/ISO
17.6
17
TNC 320 | Manuel utilisateur Programmation en DIN/ISO | 7/2014
557
Adresses
T
T
T
Définition d'outil avec G99
Appel d'outil
Outil suivant avec G51
U
V
W
Axe parallèle à l'axe X
Axe parallèle à l'axe Y
Axe parallèle à l'axe Z
X
Y
Z
Axe X
Axe Y
Axe Z
*
Fin de séquence
Cycles de contour
Format du programme d'usinage avec plusieurs outils
Liste des sous-programmes de contour
G37 P01 ...
Définir les
données du contour
G120 Q1 ...
Définir/appeler le foret
Cycle de contour : Prépercer
Appel de cycle
G121 Q10 ...
Définir/appeler la fraiseuse de dégrossissement
Cycle de contour : Evidement
Appel de cycle
G122 Q10 ...
Définir/appeler la fraiseuse de finition
Cycle de contour : Finition en profondeur
Appel de cycle
G123 Q11 ...
Définir/appeler la fraiseuse de finition
Cycle de contour : Finition page
Appel de cycle
G124 Q11 ...
Fin du programme principal, saut de retour
M02
Sous-programmes de contour
G98 ...
G98 L0
Correction de rayon des sous-programmes de contour
Contour
Suite chronologique de programmation des éléments de
contour
Correction de
rayon
A l'intérieur
(poche)
dans le sens horaire (CW)
dans le sens anti-horaire (CCW)
G42 (RR)
G41 (RL)
A l'extérieur (îlot)
dans le sens horaire (CW)
dans le sens anti-horaire (CCW)
G41 (RL)
G42 (RR)
