Résumé des fonctions din/iso 17.6 – HEIDENHAIN TNC 320 (77185x-01) ISO programming Manuel d'utilisation
Page 555
Résumé des fonctions DIN/ISO
17.6
17
TNC 320 | Manuel utilisateur Programmation en DIN/ISO | 7/2014
555
Fonctions G
Cycles palpeurs pour initialiser le point d'origine
G408
G409
G410
G411
G412
G413
G414
G415
G416
G417
G418
G419
Point d'origine centre rainure
Point d'origine centre ilot oblong
Point d'origine à l'intérieur du rectangle
Point d'origine à l'extérieur du rectangle
Point d'origine à l'intérieur du cercle
Point d'origine à l'extérieur du cercle
Point d'origine à l'extérieur de l'angle
Point d'origine à l'intérieur de l'angle
Point d'origine au centre du cercle
Point d'origine dans l'axe du palpeur
Point d'origine au centre de 4 trous
Point d'origine sur un axe au choix
Cycles palpeurs pour la mesure des pièces
G55
G420
G421
G422
G423
G424
G425
G426
G427
G430
G431
Mesurer des coordonnées quelconques
Mesurer un angle quelconque
Mesurer un trou
Mesurer un tenon circulaire
Mesurer une poche rectangulaire
Mesurer un tenon rectangulaire
Mesurer une rainure
Mesurer la largeur d'un ilot oblong
Mesurer des coordonnées quelconques
Mesurer le centre d'un cercle
Mesurer un plan au choix
Cycles palpeurs pour l'étalonnage des outils
G480
G481
G482
G483
Calibrer TT
Mesurer la longueur d'outil
Mesurer le rayon d'outil
Mesurer la longueur et le rayon d'outil
Cycles spéciaux
G04*
G36
G39*
G62
G440
G441
Temporisation en secondes
Orientation de la broche
Appel de programme
Ecart de tolérance pour le fraisage rapide de contours
Mesurer le décalage des axes
Palpage rapide
Définition du plan d’usinage
G17
G18
G19
G20
Plan X/Y, axe d'outil Z
Plan Z/X, axe d'outil Y
Plan Y/Z, axe d'outil X
axe d'outil IV
Cotations
G90
G91
Cotation en absolu
Cotation en incrémental
Unité de mesure
G70
G71
Unité de mesure, pouce (à définir en début de programme
Unité de mesure, millimètre (à définir en début de programme)
