HEIDENHAIN TNC 320 (77185x-01) ISO programming Manuel d'utilisation
Page 248
![background image](/files/816032/content/doc248.png)
Programmation : sous-programmes et répétitions de parties de
programme
8.6
Exemples de programmation
8
248
TNC 320 | Manuel utilisateur Programmation en DIN/ISO | 7/2014
N170 G98 L1 *
Début du sous-programme 1 : figure de trous complète
N180 G00 G40 G90 X+15 Y+10 M3 *
Aborder le point initial du groupe de trous 1
N190 L2,0 *
Appeler le sous-programme 2 du groupe de trous
N200 X+45 Y+60 *
Aborder le point initial du groupe de trous 2
N210 L2,0 *
Appeler le sous-programme 2 du groupe de trous
N220 X+75 Y+10 *
Aborder le point initial du groupe de trous 3
N230 L2,0 *
Appeler le sous-programme 2 du groupe de trous
N240 G98 L0 *
Fin du sous-programme 1
N250 G98 L2 *
Début du sous-programme 2 : groupe de trous
N260 G79 *
Appeler le cycle pour le trou 1
N270 G91 X+20 M99 *
Aborder le 2ème trou, appeler le cycle
N280 Y+20 M99 *
Aborder le 3ème trou, appeler le cycle
N290 X-20 G90 M99 *
Aborder le 4ème trou, appeler le cycle
N300 G98 L0 *
Fin du sous-programme 2
N310 %UP2 G71 *
