Mode manuel et réglages
13.4 Initialiser le point d'origine sans palpeur 3D
13
398
TNC 320 | Manuel utilisateur Programmation en DIN/ISO | 7/2014
Fonction
Softkey
Entrer directement le nouveau point d'origine
(spécifique à un axe) sans tenir compte de
la cinématique. N'utiliser cette fonction que
si votre machine est équipée d'un plateau
circulaire et si vous désirez initialiser le point
d'origine au centre du plateau circulaire
en introduisant directement la valeur 0. La
fonction ne mémorise la valeur que sur l'axe
actuellement la surbrillance. Introduire la
valeur souhaitée dans la fenêtre auxiliaire Avec
l'affichage en pouces (inches) actif : Entrer la
valeur en pouces (inches). La TNC convertit la
valeur saisie en mm.
Sélectionner TRANSFORM. DE BASE/
OFFSET.AXE Dans l'affichage standard
TRANSFORM. DE BASE, la commande affiche
les colonnes X, Y et Z. En fonction de la
machine, la commande affiche également les
colonnes SPA, SPB et SPC. La TNC mémorise
ici la rotation de base (avec l'axe d'outil Z,
la TNC utilise la colonne SPC). Dans la vue
OFFSET, la commande affiche les valeurs de
décalage du Preset.
Inscrire le point de référence actuellement
actif sur une ligne sélectionnable du tableau :
La fonction mémorise le point de référence
sur tous les axes et active automatiquement
la ligne du tableau concernée. Avec l'affichage
en pouces (inches) actif : Entrer la valeur en
pouces (inches). La TNC convertit la valeur
saisie en mm.
