Tableaux et résumés
17.3
Informations techniques
17
518
TNC 320 | Manuel utilisateur Programmation en DIN/ISO | 7/2014
Accessoires
■
une manivelle portable HR 410 ou
■
une HR 550 FS : manivelle radio portable avec affichage ou
■
une HR 520 : manivelle portable avec affichage ou
■
une HR 420 : manivelle portable avec affichage ou
Manivelles électroniques
■
une HR 130 : manivelle encastrable ou
■
jusqu’à trois HR 150 : manivelles encastrables via l'adaptateur de
manivelles HRA 110
■
TS 220 : palpeur 3D à commutation avec liaison par câble
■
TS 440 : palpeur 3D à commutation avec transmission infrarouge
■
TS 444 : palpeur 3D à commutation avec transmission infrarouge, sans
pile
■
TS 640 : palpeur 3D à commutation avec transmission infrarouge
■
TS 740 : palpeur 3D à commutation avec transmission infrarouge, de
haute précision
Systèmes de palpage
■
TT 140 : palpeur 3D à commutation pour l'étalonnage d'outils
■
TT 449 : palpeur 3D à commutation et transmission infrarouge pour
l'étalonnage d'outils
Option de logiciel 1
(numéro d'option #08)
Usinage avec plateau
circulaire
■
Programmation de contours sur le développé d'un cylindre
■
Avance en mm/min
Conversions de
coordonnées
■
Inclinaison du plan d'usinage
Interpolation
■
Cercle dans 3 axes avec plan incliné (cercle dans l'espace)
HEIDENHAIN DNC
(numéro d'option #18)
■
Communication avec applications PC externes au moyen de
composants COM
Option de logiciel Convertisseur DXF
(numéro d'option #42)
■
Format DXF accepté : AC1009 (AutoCAD R12)
■
Pour contours et motifs de points
■
Définition pratique du point d'origine
Extraction de programmes
de contour et de positions
d'usinage à partir de
données DXF Extraction de
contours partiels à partir de
programmes avec dialogue
Texte clair
■
Sélection graphique de contours partiels à partir de programmes
Dialogue Texte clair
