Informations techniques
17.3
17
TNC 320 | Manuel utilisateur Programmation en DIN/ISO | 7/2014
519
Formats d'introduction et unités des fonctions TNC
Positions, coordonnées, rayons de cercles,
longueurs de chanfreins
-99 999.9999 à +99 999.9999
(5,4 : chiffres avant la virgule, chiffres après la virgule) [mm]
Numéros d'outils
0 à 32 767,9 (5,1)
Noms d'outils
16 caractères, écrits entre ““ avec
TOOL CALL
.
Caractères spéciaux autorisés : #, $, %, &, -
Valeurs Delta des corrections d'outils
-99,9999 à +99,9999 (2,4) [mm]
Vitesses de rotation broche
0 à 99 999,999 (5.3) [tours/min.]
Avances
0 à 99 999,999 (5,3) [mm/min] ou [mm/dent] ou [mm/tour]
Temporisation dans le cycle 9
0 à 3 600,000 (4,3) [s]
Pas de vis dans divers cycles
-99,9999 à +99,9999 (2,4) [mm]
Angle pour orientation de la broche
0 à 360,0000 (3,4) [°]
Angle des coordonnées polaires, rotation,
inclinaison du plan d'usinage
-360,0000 à 360,0000 (3,4) [°]
Angle des coordonnées polaires pour
l'interpolation hélicoïdale (CP)
-5 400,0000 à 5 400,0000 (4,4) [°]
Numéros de points zéro dans le cycle 7
0 à 2 999 (4,0)
Facteur échelle dans les cycles 11 et 26
0,000001 à 99,999999 (2,6)
Fonctions auxiliaires M
0 à 999 (4,0)
Numéros de paramètres Q
0 à 1999 (4,0)
Valeurs des paramètres Q
-99 999,9999 à +99 999,9999 (9.6)
Vecteurs normaux N et T pour la
correction 3D
-9,99999999 à +9,99999999 (1,8)
Marques (LBL) pour sauts de programmes
0 à 999 (5,0)
Marques (LBL) pour sauts de programmes
N'importe quelle chaîne de texte entre guillemets (““)
Nombre de répétitions de parties de
programme REP
1 à 65 534 (5,0)
Numéro d'erreur avec la fonction des
paramètres Q FN14
0 à 1 199 (4,0)
