5 utiliser un palpeur 3d, Résumé, Utiliser un palpeur 3d – HEIDENHAIN TNC 320 (77185x-01) ISO programming Manuel d'utilisation
Page 401: Utiliser un palpeur 3d 13.5
Utiliser un palpeur 3D
13.5
13
TNC 320 | Manuel utilisateur Programmation en DIN/ISO | 7/2014
401
13.5
Utiliser un palpeur 3D
Résumé
En
mode Manuel, les cycles palpeurs suivants sont disponibles :
HEIDENHAIN ne garantit le fonctionnement
correct des cycles de palpage qu'avec les palpeurs
HEIDENHAIN.
La TNC doit avoir été préparée par le constructeur
de la machine pour l'utilisation des palpeurs 3D.
Consultez le manuel de votre machine !
Fonction
Softkey
Page
Etalonnage de la longueur
effective
Etalonnage du rayon effectif
Détermination de la rotation de
base à partir d'une droite
Initialisation du point d'origine
sur un axe au choix
Initialisation d'un coin comme
point d'origine
Initialisation du centre de cercle
comme point d'origine
Initialisation de la ligne médiane
comme point d'origine
Gestion des données du palpeur
Voir manuel
d'utilisation
des cycles
Pour de plus amples informations sur le tableau des
palpeurs, veuillez consulter le Manuel d'utilisation,
Programmation des cycles.
