N 79 G0 Y0
N 80 G14 Q0
N 81 M105
N 82 M109
N 83 G714 ID"B_322-1000.10" O0 B75 C0 [// Centrage 10mm - externe - surface enveloppe]
N 84 G197 S1146 G195 F0.1 M103
N 85 M108
N 86 G0 X126 Z-25
N 87 G147 K2
N 88 G72 NS15 K75
N 89 G14
N 90 M105
N 91 M109
N 92 G714 ID"B_332-0500.10" O0 B75 C0 [// Parçage 5mm - externe - surface enveloppe]
N 93 G197 S2228 G195 F0.08 M103
N 94 M108
N 95 G0 X126 Z-17.5
N 96 G0 Y30
N 97 G147 K2
N 98 G71 NS15 E0.05 K75
N 99 G0 X126 Z-32.5
N 100 G0 Y0
N 101 G14 Q0
N 102 M105
N 103 M109
N 104 G714 ID"372-600.10" O0 B75 C0 [// Filet M6 - externe - surface enveloppe]
N 105 G197 S1000 G195 F1 M103
N 106 M108
N 107 G0 X126 Z-17.5
N 108 G0 Y30
N 109 G147 K5
N 110 G73 NS15 B5 K75
N 111 G0 X126 Z-32.5
N 112 G0 Y0
N 113 G14 Q0
N 114 M105
N 115 M109
