33
CARE AND MAINTENANCE
BATTERY REPLACEMENT:
1. Remove drip pan.
2. Pull battery downward (This may require use of pliers.)
3. Re-install upward and push to snap in - Fig. 60.
(Polarity is shown in Fig. 61).
Note:
Battery condition should be checked at least once a year.
REGULATOR AND HOSE REPLACEMENT
The pressure regulator and hose assembly supplied with the unit must be used. If replacements are needed, con-
tact Customer Care for orders at (888) 936-7872. Do not use the outdoor appliance if the odor of gas is present.
If the unit is LP, screw the regulator into the tank and leak check the hose and regulator connections with a soap
and water solution before operating the outdoor appliance. Turn all knobs to “OFF” then turn on the gas supply.
If LP, confirm there is gas in the tank.
n Always keep your face and body as far away from the outdoor appliance as possible when lighting.
n
DO NOT leave the outdoor appliance unattended while cooking.
n
Keep a spray bottle of soapy water near the gas supply valve and check the connections before each use.
n Do not attempt to “LIGHT” the outdoor appliance if the odor of gas is present.
n Wait 5 minutes before relighting a hot outdoor appliance.
CLEANING GRILL GRATES:
The easiest way to clean the grill grates is immediately after cooking is completed and after turning off the flame.
Wear a barbeque mitt to protect your hand from the heat and steam. Dip a fine stainless steel bristle barbeque
brush in tap water and scrub the hot grates. Dip the brush frequently in the bowl of water. Steam, created as
water contacts the hot grates, assists the cleaning process by softening any food particles. The food particles will
fall onto the ceramic rods and burn or fall into the drip pan. If the grill is allowed to cool before cleaning, clean-
ing will be more difficult. After cleaning, apply a thin coat of vegetable oil to protect the grate from moisture and
rust stains.
WARNING!
Do not put grease down any drain or sink. Place the cool grease in a container and throw into the trash.
DRIP PAN AND GREASE TRAY/GREASE CUP:
The full width drip pan with grease tray will collect grease from the outdoor appliance. Allow the pan and its
contents to cool before attempting to clean. The griddle grease cup is dishwasher safe.
To remove drip tray: (if needed)
n
Pull tray out until it stops.
n
Continue pulling the tray out to clean.
To install drip tray:
n Align the side of the drip tray with the guides (Fig. 62).
n
Push the tray in until it stops.
n Pull the tray forward and push in and out several times to engage
rollers.
Fig. 61 Fig. 60
Fig. 62
Guide
