15
INSTALLATION
CART ASSEMBLY INSTRUCTIONS
Step 4
Gas Hookup - LP
Make sure the cart assembly is stable. Open the tank drawer. Place the LP tank into location as shown in Fig. 17.
Connect the regulator assembly to the tank connection with all appliances valves in the “OFF” position. Open the
tank valve and test for gas leaks (Fig. 18).
Fig. 17 Fig. 18
FOR YOUR SAFETY
To prevent personal injury or damage to the drawers, do not overload them. The maximum rating of each drawer is
35 pounds.
WARNING!
Do not push down on the top of the drawers. The unit could tip forward.
Fig. 19
Cover hanger
Fig. 20
Fig. 21
COVER HANGER
To use the cover hangers provided, first place the cover hanger
into the slot on the side or rear of your Cart (Fig. 19). Then hang
the cover in either direction. (Fig. 20 or 21).
Note:
Do not move the cart while the covers are hung. This could cause
the covers to fall off the hangers and damage the covers.
EN
