188 Chapter 3 - OCP 42/OCP 50 Maintenance
Access to the various units
B1500M24LA
September 2000
THOMSON OCP 42/OCP 50
User manual
3.1.4.2 - TOP KEYBOARD and BOTTOM KEYBOARD boards
• Remove the MPU BOARD.
• To remove the TOP KEYBOARD, unscrew both Hexagonal pillars.
• To remove the BOTTOM KEYBOARD, remove the 4 Hexagonal pillars.
J3
J1 J2
J14
Z100
Z200
Z130
TP4
TP2
TP1
TP3
TP5
J12
J13
Z120 Z110
R1
Screws
