Chapter 1 - OCP 42/OCP 50 Installation 113
Description and connection of connectors
THOMSON OCP 42/OCP 50
User manual
B1500M24LA
September 2000
1.3.4.2 - Adaptation to type 1542 OCP wiring
Connection of the PREVIEW socket of the OCP 40 to a cable assembly produced for type 1542
OCP calls for the use of one of the following adapter cables:
The wiring sides of the connectors are shown.
Loop type control Voltage type control
Connector
Type : PT01E10/6P01SR
P/N : T1005664 Connector
Type : HE501 PFD-09Z
P/N : T9000370
Cap
Type :86303920A
P/N: 91617109 Connector
Type : PT01E10/6P01SR
P/N : T1005664 Connector
Type : HE501 PFD-09Z
P/N : T9000370
Cap
Type :86303920A
P/N : 91617109
Note: The part number for this cable is
B1500552 (length 20 cm).
Note: The part number for this cable is
B1500552 (length 20 cm).
1
5
6
9
B
C
D
E
F
A
PREVIEW SW OUT
PREVIEW SW OUT
PREVIEW IN (-)
PREVIEW IN (+)
GROUND
1
5
6
9
B
C
D
E
F A
PREVIEW SW OUT
PREVIEW SW OUT
PREVIEW IN (-)
PREVIEW IN (+)
