Chapter 1 - OCP 42/OCP 50 Installation 125
Setting up
THOMSON OCP 42/OCP 50
User manual
B1500M24LA
September 2000
Pressing of the NEXT button displays the 2nd Channel Control Unit setting up page.
If the panel is connected to a multiconductor EFP, this page is used to modify the following
parameters:
• H PHASE: Adjustment of the horizontal phase of the Channel Control Unit output videos
with respect to the GEN LOCK input signal.
• SC PHASE: Phase adjustment of the encoded output video subcarrier of the Channel Control
Unit with respect to the GEN LOCK input signal.
0 2 0) 5 - 5 + 2 0) 5 -
" & #
