Chapter 1 - OCP 42/OCP 50 Installation 105
Cases of use (operating configurations)
THOMSON OCP 42/OCP 50
User manual
B1500M24LA
September 2000
1.1 - CASES OF USE (OPERATING CONFIGURATIONS)
The operational control panel connects to the following items of equipment:
TTV 1657D
+ VTR:
TTV 1657D
+ Remoted VTR:
TTV 1657D
+ multi-conductor EFP:
TTV 1657D
+ TRIAXIAL EFP CA85 APCM:
TTV 1657D
+ TRIAXIAL EFP CA85,
CCU1685 OR 1686:
VTR CAMERA
OCP 42/50
REMOTE
CA25 CAMERA
OCP 42/50
REMOTE
VTR
CA25 CAMERA
OCP 42
CCU 1625
1657D : with or without option APCM
CA85 CAMERA
OCP 42/50
CCU 1542
APCM
CA85 CAMERA
OCP 42/50
CCU 1685
CCU 1686
