114 Chapter 1 - OCP 42/OCP 50 Installation
Connection to camera
B1500M24LA
September 2000
THOMSON OCP 42/OCP 50
User manual
1.4 - CONNECTION TO CAMERA
Connect the panel CCU socket to the «Remote» connector on the camera using the special
cable carrying the panel power supply (12 V) and the RS422 link simultaneously.
Make sure to set the «LOOP/150 Ohm» switch to 150 Ohms.
NOTE: No other panel can be connected to the camera head.
