Le diagramme suivant présente un aperçu de la structure du menu :
11-1 VacInverter
11-2 AmpacInverter
11-3 FacInverter
11-4 PacInverter
12-1 BatVoltage
12-2 BatCurrent
12-3 BatTemp
12-4 BatState
12-5 BatChargeMode
12-6 TabsorbLeft
12-7 BatChargeVolt
13-1 VacGenerator
13-2 AmpacGenerator
13-3 FacGenerator
13-4 PacGenerator
21-1 Level [00] *****
22-1 VacNominal
23-1 VdcBatNominal
23-2 BatType
23-3 AmpHoursBat
23-4 AmpdcBatMax
24-1 GenControl
24-2 AmpacGenMax
24-3 GenOperation
31-1 DeviceConfig
31-2 FWVERS
31-3 SerNum
31-4 RunTime
32-1 Last
32-2 Hist
11 Inverter Meters
12 Battery Meters
13 Generator Meters
21 Password Settings
22 Inverter Settings
23 Battery Settings
24 Generator Settings
31 System Information
32 Error Information
40-1 BatChargeMode
40-2 Autostart
Home Screen
10 METERS
System Meters
20 SETTINGS
System Settings
30 DIAGNOSE
System Diagnose
40 OPERATION
System Operation
11-5 TrfTemp
11-6 HsTemp
23-5 NewBattery
23-6 TabsorbBoost
23-7 VchargeBoost
23-8 TabsorbEqual
23-9 VchargeEqual
23-10 TabsorbFull
23-11 VchargeFull
23-12 VchargeFloat
23-13 TcycleFull
23-14 TcycleEqual
23-15 SOCLim1
23-16 SOCLim2
23-17 SOCLim3
23-18 TBatMax
24-4 VacGenMax
24-5 VacGenMin
24-6 FacGenMax
24-7 FacGenMin
24-8 GridConnected
24-9 DelayVGenLow
24-10 Transition
24-11 PGenRevers
24-12 PGenActiv
24-13 PGenTAve
24-14 PGenTRun
24-15 PGenOn
24-16 PGenOff
40-3 BaudRate
40-4 ParameterSet
40-6 LoadShedding
40-7 GenRequest
40-8 SunnyBoys
40-9 Offset_Calib
Installer Level User Level
