Multi-Contact MA076 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 8
IS21-C...
14.2019C...-* VK-S21
15.5860
MA076 (fr_en)
Notice de montage MA076 (fr_en)
Assembly instructions
Broche IS21-C... à verrouillage baïonnette avec
embout fi leté Plug IS21-C... with bayonet locking and threa-
ded stud
Contenu
Consignes de sécurité ................................................................2
Outillage nécessaire ..................................................................3
Montage sur barre conductrice .................................................3
Connexion .................................................................................3
Bouchon de protection ..............................................................4
Codage ......................................................................................4
Verrouillage supplémentaire ......................................................4
Phase d‘embrochage/Contrôle/Phase de débrochage ..............5
Vérifi er le joint d‘étanchéité KBT21 ...........................................6
Notes ......................................................................................7-8 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Assembly into busbar ................................................................3
Connection ................................................................................3
Fitting the protective cap ...........................................................4
Coding .......................................................................................4
Safety latch ................................................................................6
Plugging, test and unplugging procedures ...............................5
Check KBT21 seal ......................................................................6
Notes ......................................................................................7-8
