Multi-Contact MA070 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 8
B...AX/...
S...AX/...
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA070 (fr_en)
Notice de montage MA070 (fr_en)
Assembly instructions
Connecteurs cylindriques avec raccordement
AxiClamp
B8AX/25-35, B12AX/50-70,
B16AX/95-120, B20AX/150-185
S8AX/25-35, S12AX/50-70,
S16AX/95-120, S20AX/150-185 Round connectors with AxiClamp termination
B8AX/25-35, B12AX/50-70,
B16AX/95-120, B20AX/150-185
S8AX/25-35, S12AX/50-70,
S16AX/95-120, S20AX/150-185
Sommaire
Consignes de sécurité ................................................................2
Outillage nécessaire ..................................................................3
Préparation du câble ..................................................................3
Raccordement du câble avec AxiClamp ....................................3
Montage sur panneau ...............................................................4 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Cable preparation ......................................................................3
Cable termination with AxiClamp ..............................................3
Assembly in panel .....................................................................4
Broche
Plug
Raccord AxiClamp
AxiClamp termination Douille
Socket
Raccord AxiClamp
AxiClamp termination
