Multi-Contact MA034 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 4
FSA20A-K/...
FSA20A-L/...
1) Suitable as set (blade and cylinder pin)
FSA20A-KL-SET Order No. 12.0890
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA034 (fr_en)
Notice de montage MA034 (fr_en)
Assembly instructions
Changement de la lame du boulon de contact
des fourches FSA20A-K/... FSA20A-L/... Changing the blade on the contact bolt of the
fl at contact clamps FSA20A-K/... FSA20A-L/...
Sommaire
Consignes de sécurité ................................................................2
Notwendiges Werkzeug ............................................................3
Démontage ................................................................................3
Montage ....................................................................................4 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Dismantle ..................................................................................3
Assembly ...................................................................................4
Lame 1)
Blade 1)
Ø 2.5x14
Goupille
1)
Cylinder pin 1)
Boulon de contact
Contact bolt
1) Livré en lot (lame et groupille)
FSA20A-KL-SET No. de Cde 12.0890
