Multi-Contact MA037 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 4
ID/B6AR-N/10-S
ID/B6AR-N/16-S
ID/B6AR-N/25-S
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA037 (fr_en)
Notice de montage MA037 (fr_en)
Assembly instructions
Douilles de sécurité à encastrer ID/B6AR-N...-S Safety fl ush-mounting sockets ID/B6AR-N...-S
Sommaire
Consignes de sécurité ................................................................2
Outillage nécessaire ..................................................................3
Préparation du câble ..................................................................3
Montage ....................................................................................3 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Preparation of the cable ............................................................3
Assembly ...................................................................................3
Douille avec fыt а sertir
Socket housing with crimp sleeve Ecrou M18x1
Nut M18x1
