Multi-Contact MA013 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 4
FMA10... FMA12-PF...
A = Wire clamp
G = Upper grip
K = Push head
L = Cable
S = Screws
S1 = Plastic screw
U = Lower grip
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA013 (fr_en)
Notice de montage MA013 (fr_en)
Assembly instructions
Pince de mesure pour contact plat
FMA10..., FMA12-PF... Flat contact clamp FMA10..., FMA12-PF...
Sommaire
Consignes de sécurité ................................................................2
Outillage nécessaire ..................................................................3
Préparation ................................................................................3
Montage ....................................................................................3
Consignes de sécurité ...............................................................4
Connexion .................................................................................4
Maintenance ..............................................................................4
Mise en place et remplacement du fusible ...............................4 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Preparation ................................................................................3
Assembly ...................................................................................3
Safety requirements ..................................................................4
Contact ......................................................................................4
Service .......................................................................................4
Fitting and replacing the fuse ....................................................4
A = Orifi ce de raccordement
G = Cache
K = Bouton poussoir
L = Câble
S = Vis
S1 = Vis en matière plastique
U = Poignée
