27" Double oven dimensions en-us
13
*Junction box location: above, left or right of the unit within
reach of the flexible conduit.
Control panel overlap: min. 3/8" (10mm) to max.
2" (51mm).
8.3 27" Single oven flush mount installation
Flush installation requires two side cleats to be attached
inside the cabinet frame, recessed from the front.
Top view
Reveal cleats
Flush inset depth
Side view
Reveal cleats
Flush cutout height
8.4 27" Single oven under-counter installa-
tion
* Includes ¾” (19 mm) base plate.
**Junction box location: right or left of the unit within range
of the flexible conduit.
27" Double oven dimensions 9 27" Double oven dimensions
27" Double oven dimensions Read here for appliance and cabinet dimensions for
27" double ovens.
9.1 27" Double oven appliance dimensions
