Multi-Contact MA074 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 8
KST21...
15.0676C...-* - 15.0683C...-*
VK-S21
15.5860
VK-B21
15.5861
KBT21...
15.0668C...-* - 15.0675C...-*
MA074 (fr_en)
Notice de montage MA074 (fr_en)
Assembly instructions
Connecteurs libres
KBT21/M40/...-C..., KBT21/M50/...-C...
KST21/M40/...-C..., KST21/M50/...-C... Free connectors
KBT21/M40/...-C..., KBT21/M50/...-C...
KST21/M40/...-C..., KST21/M50/...-C...
Contenu
Consignes de sécurité ................................................................2
Outillage nécessaire ..................................................................3
Montage du câble .....................................................................3
Préparation du joint en caoutchouc du presse-étoupe .............3
Préparation du câble ..................................................................4
Sertir le câble .............................................................................4
Montage ....................................................................................5
Montage du capuchon ..............................................................5
Codage ......................................................................................6
Verrouillage supplémentaire ......................................................6
Phase d‘embrochage et débrochage - Contrôle ........................7
Vérifi er le joint d‘étanchéité KBT21 ...........................................8 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Cable assembly .........................................................................3
Preparing the rubber seal of the cable gland ............................3
Cable preparation ......................................................................4
Crimping the cable ....................................................................4
Assembly ...................................................................................5
Fitting the protective cap ...........................................................5
Coding .......................................................................................6
Safety latch ................................................................................6
Plugging, test and unplugging procedures ...............................7
Check KBT21 seal ......................................................................8
