WARNING
Falling Object Hazard
Not following Installation Instructions
for mounting your air conditioner can
result in property damage, injury, or
death.
Standard Window Installation
Figure 53
STEP 1. Fold down the sides of the carton bottom tray (Figure 53).
STEP 2. Install side curtains (B in parts list) on both sides of the unit.
Press in the attached push pins (4 on each side) to secure
curtains to the sleeve (Figure 54).
Figure 54
STEP 3. Once both curtains have been installed, slide hands underneath
the unit to lift and carry to the window, as shown in Figure 55
below. Obtain assistance as needed.
CAUTION
Excessive Weight Hazard
Use two or more people when installing your
air conditioner.
Failure to do so can result in back or other
injury.
Figure 55
NOTE: WHEN REMOVING UNIT FROM SLEEVE AND CARRYING
OR HANDLING UNIT, OBTAIN ASSISTANCE OR HELP
AS NECESSARY TO SUPPORT UNIT FROM BOTTOM
(BASEPAN), MAINTAINING CLEARANCE FROM ALL
OBSTACLES.
