NOTE: Protective clothing and gear should be worn & used while installing the unit (e.g. protective eye wear, gloves, boots, etc…)
FOR WINDOW INSTALLATIONS, PROCEED TO THE NEXT PAGE.
FOR THRU-THE-WALL INSTALLATIONS, SKIP TO PAGE 34.
D
Installation Hardware and Accessory Details
B
Installation Hardware
ITEM
NO
DESCRIPTION
QTY.
E
F
G
SCREW #8 x ½" (BLUE BAG)
SCREW #8 x 1 ¼" (GREY BAG)
SPARE PUSH PINS
6
5
4
Installation Hardware
ITEM
NO
DESCRIPTION
QTY.
A
B
C
D
Q KÜHL UNIT
Q SIDE CURTAINS (INCLUDES 8 PUSH PINS)
WINDOW SEAL GASKET
SHELL GASKET (ADHESIVE-BACK)
for replacement installations only
1
2
1
1
