Airflow Selection and Adjustment
LEFT
AIRFLOW
LEVER
RIGHT
AIRFLOW
LEVER
Figure 52
FRR008
Airflow direction adjustment
The airflow path may be adjusted to distribute air independently from the
left or right side of the discharge opening. Each of the banks of louvers can
be directed left, right, up, or down in order to achieve the most optimum
airflow positioning.
To adjust airflow direction, grab the lever in the center of the louver bank
and move it in the direction that you would like the air to be directed. Please
note that it is normal that airflow may be stronger out of one side of the
louvers than the other.
