86
MAINTENANCE
Drive Belt
Check Drive Belt Condition
Replace the drive belt if it is cracked or has broken teeth or frayed edges. No matter its condition, the drive belt should
be replaced at periodic intervals (see the VICTORY Service Manual or an authorized VICTORY dealer). DO NOT attempt
to check belt tension if the belt has been exposed to rain or washing within a 24 hour period or if the belt is hot from riding. Allow
the belt to cool down to ambient temperature before measuring belt tension. To obtain the maximum drive belt service life
possible, Victory recommends the replacement of both sprockets as a set if the drive belt system has over 5,000 miles (8,000 km)
of service at the time of damage or failure.
Check Drive Belt Tension
This procedure involves using the belt tension gauge, part no. PV-43532,
which is designed specifically for measuring drive belt tension.
Before beginning this procedure:
S Make sure the drive system is dry and at room temperature.
S Make sure the rear suspension is properly adjusted (see Adjust Rear
Shock Absorber, page 92).
1. Place the transmission in Neutral and lift the rear wheel off the ground
with an appropriate motorcycle lift or a block of wood or steel placed
securely under the frame.
Care should be taken to be sure the motorcycle will not tip or fall while elevated. Severe personal
injury or death may occur if the motorcycle tips or falls.
WARNING
1. Belt Tension
Gauge
2. Small O-Ring
3. Base
4. Plunger
1
2
3
4
