154
SPECIFICATIONS
Model Year 2007 VEGAS JACKPOT / NESS JACKPOT
Engine
Engine Type Freedom ® 100 / 6 V--Twin
Configuration Freedom ® 100/6 50_ V-Twin 4 Stroke
Displacement 100 cu in (1634 cc)
Cooling System / Oiling System / Oil Capacity Air & Oil / Wet Sump / 5.0 qt. (4.75ltr)
Compression Ratio 9.8:1
Valve Train SOHC - 4 Valves Per Cylinder With Hydraulic Lifters
& Hydraulic Cam Chain Adjusters
Bore and Stroke 101 x 102 mm
Fuel System / Throttle Body Bore Electronic Fuel Injection / 44 mm
Exhaust System Dual-Large Bore Slash-Cut with Common Volume
Spark Plug / Gap NGK CPR6EB-9 .032 in (0.8 mm)
Chassis
Fork Tube Diameter / Front Suspension Type / Travel 43mm / Conventional Telescopic Fork /
5.1 in (13.0 cm)
Rear Suspension Type / Travel Single, Monotube Gas,
Preload Adjustable / 3.0 in (7.5 cm)
Swingarm Forged and Cast Aluminum
With Rising Rate Linkage
Front Brakes Single 300 x 5 mm Floating Rotor
4 Piston Caliper
Rear Brakes Single 300 x 5 mm Floating Rotor
2 Piston Caliper
NOTE: Dimensions and specifications may vary with features, options and accessories.
