Polaris 2007 Victory Ness Signature Series Vegas Jackpot - Manuel (Page 60)

1/8-1/4 inch
(3-6mm)
56
PRE-OPERATION CHECK
Check Brakes
Check Hoses and Connections
Inspect all brake hoses and connections for dampness or stains
from leaking or dried fluid. Tighten any leaking connections and
replace components as necessary. Refer to the Victory Service
Manual for torque values of fasteners or contact your Victory
dealer.
Check Brake Pads
Look at the front brake pads at (1), and rear brake pads at (2). You
should see at least 1/16 inch (1.6 mm) of friction material on each
of the brake pads (see page 113). If in doubt, measure remaining
friction material. Replace brake pads having less than the specified
amount of friction material at their thinnest point.
Check Throttle Control Grip and Cables
1. Rotate the throttle control grip. It should rotate smoothly
from its rest position to its completely open position and
back again. It should return to its rest position quickly when
released.
2. Throttle freeplay, the amount of throttle control grip
movement from the rest position to the point of cable
resistance, should be 1/8-1/4 inch (3-6 mm).
3. Adjust throttle cable freeplay if necessary (see page 102).
2
1
