1
2
3
7
10
6
9
11
12 14 15 17 18 19 20 21 13
8
4
5
16
31
COMPONENT IDENTIFICATION
LEFT SIDE VIEW
1. Front Fork
2. Front Turn Signal
3. Headlamp
4. Air Filter
5. Spark Plug (2)
6. Ignition Switch
7. Left Side Cover
8. Battery (under side cover)
9. Taillight
10. Rear Turn Signal
11. Rear Axle Adjuster (1 each side)
12. Rear Brake Caliper
13. Passenger’s Foot Rest
14. Evaporative Emissions Canister
(California Models)
15. Oil Filter
16. Oil Drain Plug
17. Sidestand
18. Operator’s Foot Rest
19. Gear Shift Pedal
20. Horn
21. Front Brake Caliper
