104
MAINTENANCE
Clutch
Lubricate Clutch Lever
1. Remove right side cover.
2. Slide the rubber cover off the cable adjuster, and loosen the
adjuster lock nut (see page 105.)
3. Turn the cable adjuster all the way in to provide maximum
lever free play.
4. Remove clutch lever pivot nut (1), and pivot screw (2).
5. Disconnect the clutch cable from the clutch lever.
6. Remove any old grease and dirt from the clutch lever and
lever housing.
7. Lubricate the clutch lever and lever pivot screw with
VICTORY Moly Assembly Grease or Victory All Purpose grease.
8. Reconnect the clutch cable and reinstall the lever and lever pivot screw.
9. Install nut.
10. Hold pivot screw down and torque nut to 40 in-lbs (5 Nm)
11. Adjust clutch freeplay (page105)
1
2
AP
