Chapter 6 - Rear adapter (CA25) 195
Views of adapter
THOMSON TTV 1657D
User manual
B1657D902C
Septembre 2000
BREAKER
RET OUT
DC IN
INCOM
Inside
Switch
CA25
VTR
CA25 adapter attaching
dovetail
Shoulder strap
pin
BREAKER
6 - RET OUT
3 - Cameraman’s
headset socket
Guide for attachment
to camera body
