194 Chapter 6 - Rear adapter (CA25)
Views of adapter
B1657D902C
Septembre 2000
THOMSON TTV 1657D
User manual
6.2 - VIEWS OF ADAPTER
VTR/CCU
MIC
INCOM
ON
AIR POWER
0
1 ON
OFF
CALL MIC ON AIR INCOM
+) #
INT
EXT
ON
OFF
ON
OFF
1 - Multi-conductor cable
socket (VTR/CCU)
2 - Microphone input
3 - Cameraman’s headset socket
4 - Auxiliary power supply input
(10.5 V to 17 V)
Accessory sockets
5 - 50-pin connector
Battery mounting
attaching holes
CALL
MIC :
ON AIR :
INCOM :
EXT
INT
ON
OFF
ON
OFF
Intercom volume
adjustment
ON AIR light
