Chapter 6 - Rear adapter (CA25)
191
THOMSON TTV 1657D
User manual
B1657D902C
Septembre 2000
Chapter 6
Rear adapter (CA25)
6.1 - Connections ................................................................ 193
6.2 - Views of adapter.......................................................... 194
6.3 - Connector definitions ................................................. 196
6.4 - Control definitions ...................................................... 200
6.4.1 - External controls ................................................................................ 200
6.4.2 - Internal controls ................................................................................. 201
6.5 - Indications ................................................................... 201
6.6 - Accessories ................................................................. 201
6.7 - Functions of internal master board switches........... 202
