166 Chapter 3 - Viewfinders
14 cm viewfinder
B1657D902C
Septembre 2000
THOMSON TTV 1657D
User manual
3.2.3 - General description
! " # $ % &
' ! " #
VIDEO IN
N.C.
N.C.
SS (Slave Select)
MOSI
N.C.
POWER IN (11V/17V)
POWER GND
VIDEO GND
SCK
ON AIR1
N.C.
MISO
N.C.
N.C.
1
2
3
4
5
9
10
11
12
6
7
8
13
14
15
Mounting attaching
Socket for connection of camera
lugs
1 kOhm/75 Ohm switch
"ON AIR 1"
Cover attaching screws
indicator
(to be set to 75 Ohms)
light
