CONFIGURATION DE LA SOURCE DE COURANT
powermax
45 Manuel de service
2-5
Tension
d’entrée Phase(s) < 10 pi 10–25 pi 25–50 pi 50–100 pi 100–150 pi
208 V c.a. 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
220 V c.a. 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
200–240 V c.a. 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
380 V c.a. 3 12 AWG 12 AWG 12 AWG 10 AWG 10 AWG
400 V c.a. 3 12 AWG 12 AWG 12 AWG 10 AWG 10 AWG
Impérial
Métrique
Tension
d’entrée Phase(s) < 3 m 3–7,5 m 7,5–15 m 15–30 m 30–45 m
208 V c.a. 1 10 mm 2 10 mm 2 10 mm 2 16 mm 2 25 mm 2
220 V c.a. 1 10 mm 2 10 mm 2 10 mm 2 16 mm 2 25 mm 2
200–240 V c.a. 1 10 mm 2 10 mm 2 10 mm 2 16 mm 2 25 mm 2
380 V c.a. 3 4 mm 2 4 mm 2 4 mm 2 6 mm 2 6 mm 2
400 V c.a. 3 4 mm 2 4 mm 2 4 mm 2 6 mm 2 6 mm 2
