Parts and Tools Needed
Parts Needed
Gas line shut-off valve Flexible metal appliance
connector ½ in (ID) x 5 ft
Flare union adapter ¾ in
(NPT) x ½ in (ID)
Flare union adapter ½ in
(NPT) x ½ in (ID)
135-degree elbow (option) 90-degree elbow (option)
Tools Needed
Flat-blade screwdriver Phillips screwdriver Open-end or adjustable
wrench
Pipe wrench (2)
¼" Nut driver Pencil, ruler Level Pipe-joint compound
Utility knife Soap-water solution Pliers Saber saw
