Viking 30 Inch Convection Microwave Hood Use and Care - Manuel (Page 30)

30 E E E 30 E 30 E 30 E
Pr
oduct Car
e
30
Specifications
AC Line Voltage: UL Rating - Single phase 120V, 60Hz, AC only
CSA Rating - Single phase 116V, 60Hz, AC only
AC Power Required: UL Rating - Microwave 1.60 kw, 13.2 amps.
UL Rating - Convection 1.60 kw, 13.2 amps.
CSA Rating - Microwave 1.5 kw, 13.0 amps.
CSA Rating - Convection 1.5 kw, 13.0 amps.
Output Power:
Microwave*
Convection Heater
850 watts
1400 watts
Frequency: 2450 MHz
Outside Dimensions: 29 15 /
16
"(W) x 16 11 /
32
"(H) x 15 9 /
32
"(D)
Cavity Dimensions: 17 1 /
8
"(W) x 8 1 /
16
"(H) x 13 13 /
16
"(D)
Microwave Oven Capacity:** 1.1 Cu. Ft.
Cooking Uniformity: Turntable and Stirrer Fan
Weight: Approx. 71 lb
* The International Electrotechnical Commission’s standardized method for measuring output wattage. This test method
is widely recognized.
** Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for holding food is
less.
In compliance with standards set by:
FCC – Federal Communications Commission Authorized.
DHHS – Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21, Chapter I, Subchapter J.
– This symbol on the nameplate means the product is listed by Underwriters Laboratories, Inc. for use in USA
or Canada.
NHW – Department of National Health and Welfare of Canada.
This microwave oven is listed by the Canadian Standard Association as certified.
