Cleaning and Care
LIGHT
1. To replace light bulbs, first disconnect power to the
microwave oven at the circuit breaker panel or by
unplugging.
2. To release cover remove the screw on the light cover.
(See illustration.)
3. Replace bulbs with only 20 watt and 40 watt bulbs.
These are available at most hardware stores or lighting
centers. The unit will be shipped with one 20 watt bulb
and one 40 watt bulb. DO NOT USE A BULB LARGER
THAN 40 WATTS.
4. Close light cover and secure with screw removed in
step 2.
Cautions: Light cover may become very hot. Do not touch
glass when light is on. Do not use light for long time use
such as a night light.
Light cover
Screw
Light
bulbs
GREASE FILTERS
Filters should be cleaned at least once a month. Never
operate the fan or microwave oven without the filters in
place.
1. Pull the ring toward the front of the microwave oven,
down slightly and remove the filter. Repeat for the other
filter.
2. Soak the filters in a sink or dish pan filled with hot water
and detergent. DO NOT use ammonia or other alkali;
they will react with the filter material and darken it.
3. Agitate and scrub with a brush to remove embedded
dirt.
4. Rinse thoroughly and shake dry.
5. Replace by fitting the filter back into the opening.
Ring
Filter
