32
49-2001159 Rev. 0
Troubleshooting Tips ...
%HIRUH\RXFDOOIRUVHUYLFH
Problem Possible Cause What To Do
Control knobs will not
turn Controls improperly set. To turn from the OFF position, push the knob in and then
turn. The knob can only be turned in a counterclockwise
direction. When the knob is at any other position, it can
be turned in either direction without being pushed in.
Fan does not work The fan control knob is improperly set. Turn knob in clockwise direction to turn fan on.
Cord improperly connected or power
turned off. &KHFNFRQQHFWLRQV7XUQRQSRZHUDWWKHIXVHER[
Poor venting Clogged filter. Clean filter per instructions.
House too airtight. Open a window slightly to provide fresh air source.
Wall cap obstructed. 5HPRYHEORFNDJHIURPH[WHULRUZDOOFDS
Wall cap damper door stuck. &KHFNH[WHULRUZDOOFDSGDPSHUGRRUIRUIUHH
movement or obstruction.
Duct length exceeds recommended 100
equivalent foot maximum. Reduce number of elbows to simplify duct run.
Tiny scratches or metal
marks (may appear as
cracks) or abrasions on
radiant cooktop glass
surface Incorrect cleaning methods being used. See the Cleaning the glass cooktop section.
Cookware with rough bottoms being
used or coarse particles (salt or sand)
are present between the cookware and
the surface of the cooktop. %HVXUHFRRNZDUHERWWRPVDQGFRRNZDUHDUHFOHDQ
EHIRUHXVH8VHFRRNZDUHZLWKVPRRWKERWWRPV7LQ\
scratches are not removable but will become less
visible in time as a result of cleaning.
Cookware has been slid across the cooktop
surface. 3LFNXSFRRNZDUHWRORFDWHLWRQWKHJODVVVXUIDFH
Areas of discoloration
or dark streaks on the
cooktop Improper cookware being used. Marks from aluminum and copper pans as well as
mineral deposits from water or food can be removed
with the cleaning cream.
Food spillovers not cleaned before next
use. See the Cleaning the Cooktop section.
Incorrect cleaning methods being used. 8VHUHFRPPHQGHGFOHDQLQJSURFHGXUHV
Hot sugar mixtures or
plastic melted to the
surface Hot cooktop came into contact with these
substances. See the Glass surface —potential for permanent damage
section in the Cleaning the Cooktop section.
Pitting (or indentation)
of the cooktop Hot sugar mixture spilled or plastic melted
on the cooktop. Call a qualified technician for replacement.
TROUBLESHOOTING TIPS
