49-2001159 Rev. 0
Installation Instructions
COOKTOP INSTALLATION (Cont.)
20. INSTALL DOWNDRAFT FILTER, VENT GASKET AND VENT GRILLE
'RQRWRSHUDWHWKHYHQWZLWKRXWWKHILOWHULQSODFH
‡3ODFHWKHILOWHUGLDJRQDOO\WKURXJKWKHYHQWRSHQLQJ
• Make sure it rests, at an angle, on the supports in
the vent opening.
• Fit the vent grille gasket around the edge of the
downdraft vent opening. Make sure the front of the
gasket is installed toward the front of the cooktop.
• Carefully place the vent grille onto the gasket on the
downdraft opening.
CHECK OPERATION OF DOWNDRAFT
‡7XUQWKHYHQWIDQVSHHGFRQWUROWR+,0('DQG/2
to make sure all speeds operate correctly.
Vent Filter
Vent
Chamber
Grille Vent Grille
Gasket
