Installation Instructions
19. ASSEMBLE BURNERS, CHECK IGNITION
Assemble burner as shown.
CAUTION
'RQRWRSHUDWHWKHEXUQHUZLWKRXWDOO
burner parts in place.
3ODFHWKHEXUQHUKHDGVRQWKHEXUQHUEDVHVPDWFKLQJ
WKHOHWWHUV3ODFHWKHFDSVRQWKHKHDGV0DNHVXUH
that the heads and caps are placed on the correct
size burner. The burner
heads and burner bases
DUHODEHOHG$%DQG&WR
aid reassembly. There is
RQHVPDOO$WZRPHGLXP
%DQGRQHODUJH&KHDG
and cap.
Make sure the notch in the burner head is positioned
toward the electrode. Rotate the burner head around
the burner base until it is level and securely seated.
3ODFHWKHJUDWHVRYHUWKHEXUQHUV
Check for proper ignition:
‡3XVKLQRQHFRQWURONQREDQGWXUQWR/,7(SRVLWLRQ
• The igniter will spark and the burner will light; the
igniter will cease sparking when the burner is lit.
• First test may require some time, while air is flushed
out of the gas line.
• Check to determine if your burner flames are normal.
If your burner flames look like A, turn off the burner
and make sure all parts are assembled correctly.
Reassemble and check. Normal burner flames
VKRXOGORRNOLNH%RU&GHSHQGLQJRQWKHW\SHRIJDV
\RXXVH:LWK/3JDVVRPH\HOORZWLSSLQJRQWKH
outer cones is normal.
• Turn knob to OFF.
• Repeat the procedure for each burner.
Grate
%XUQHUKHDG
%XUQHUFDS
Electrode
%XUQHUEDVH
Curved side
toward the
center
Medium
Head
and Cap
Medium
Head
and Cap
Front of Cooktop
Small
Head
and Cap
/DUJH
Head
and Cap
A–Yellow flames
Call for service
B–Yellow tips
on outer cones
Normal for LP gas
C–Soft blue
flames Normal
for natural gas
WHEN ALL HOOKUPS ARE COMPLETED
Make sure all controls are left in the off position. Make
sure the flow of combustion and ventilation air to the
cooktop is unobstructed. Check that all packing materials and tape have been
removed. This will include adhesive tape, wire ties,
cardboard and protective plastic. Failure to remove
these materials could result in damage to the appliance
once the appliance has been turned on and surfaces
have heated.
COOKTOP INSTALLATION (Cont.)
