49-2001159 Rev. 0
%HVXUHHOHFWULFDOSRZHULVRIIDQGDOOVXUIDFHVDUHFRROEHIRUHFOHDQLQJDQ\SDUWRIWKHFRRNWRS
Sealed Burner Assemblies
Turn all controls OFF before
removing the burner parts.
The burner grates, caps and
burner heads can be lifted off,
making them easy to clean.
CAUTION
Do not
operate the burner without all
burner parts in place.
When one burner is turned to LITE , all the
EXUQHUVVSDUN'RQRWDWWHPSWWRGLVDVVHPEOHRU
clean around any burner while another burner
is on. An electric shock may result, which could
cause you to knock over hot cookware.
Electrode
Grate
%XUQHUKHDG
%XUQHUFDS
Electrode
%XUQHUEDVH
Burner Caps, Heads and Electrodes
Burner Caps
/LIWRIIZKHQFRRO7RFOHDQWKHEXUQHUFDSVZDVKLQKRW
soapy water and rinse with clean water. You may scour
with a plastic scouring pad to remove burned-on food
particles.
Burner Heads
The slits in the burner heads of your cooktop must be
kept clean at all times for an even, unhampered flame.
You should clean the surface burners routinely,
especially after bad spillovers, which could clog these
RSHQLQJV/LIWRIIZKHQFRRO
To clean the burner heads, wash in hot, soapy water and
rinse with clean water.
To remove burned-on food, soak the burner heads in a
VROXWLRQRIPLOGOLTXLGGHWHUJHQWDQGKRWZDWHUIRU±
minutes. For more stubborn stains, use a toothbrush.
8VHDVPDOOVHZLQJQHHGOHRUSDSHUFOLSWRUHPRYHDQ\
clogs in the slits.
Electrodes
This small metal rod produces the spark and must be
kept clean and dry to properly ignite the gas.
To clean the electrodes, use a dry paper towel or
scrub pad.
After Cleaning
%HIRUHSXWWLQJWKHEXUQHUFDSVDQGKHDGVEDFNVKDNH
RXWH[FHVVZDWHUDQGWKHQGU\WKHPWKRURXJKO\E\
VHWWLQJLQDZDUPRYHQIRUPLQXWHV&KHFNWRPDNH
sure the electrodes remain seated down in burner head.
Replacement
7KHEXUQHUKHDGVDQGEXUQHUEDVHVDUHODEHOHG$%
and C to aid reassembly.
Replace the burner heads on the bases matching the
letters. Replace the caps on the heads. Make sure that
the caps and heads are replaced in the correct location.
7KHUHLVRQHVPDOO$WZRPHGLXP%DQGRQHODUJH
&KHDGDQGFDS,IWKHFDSVRUKHDGVDUHQRWUHSODFHG
in the correct locations, burners may not ignite or
perform properly.
After cleaning, make sure the notch in the burner head is positioned
toward the electrode. Rotate the burner head around the burner base
until it is level and securely seated.
NOTE: %HIRUHUHPRYLQJWKHEXUQHUFDSVDQGKHDGVUHPHPEHUWKHLU
size and location. Replace them in the same location after cleaning.
7KHEXUQHUKHDGVDQGEXUQHUEDVHVDUHODEHOHG$%DQG&WRDLG
reassembly.
B
B A
C
B
B
A
C
Medium Head
and Cap
Medium Head
and Cap
Small Head
and Cap
/DUJH+HDG
and Cap
Front of Cooktop
Cleaning the Cooktop
CARE AND
CLEANING:
Cleaning The
Cookto
p
