EN
25
14 - Gas Cooktop Operation
Gas Control Knob Setting
Electric gas ignition
The gas burners use an electric ignition device located near
each burner that by means of spark igniters ensure they ignite
automatically.
ELECTRIC IGNITION
The electronic auto re-ignition lights the surface burner when
the corresponding control knob is turned at any valve rotation
allowing sufficient gas flow to support a flame.
If any burner flame goes out for any reason, the igniter
automatically sparks to relight the flame.
NOTE: this feature is provided as a convenience
and is not intended as a safety feature. If
you detect a gas odor coming from your
range ensure all knobs are turned to the OFF
position. If odor persists turn off supply to
range and inspect connections.
To set:
• Push and turn a knob counter clockwise to any setting, the
corresponding spark plugs will generate a clicking sound
(spark), the burner will produce a flame and reignite
automatically if the flame goes out.
WARNING
• Do not operate a burner using empty cookware or without
cookware on the grate.
• Do not touch the burner when the igniters are clicking
(sparking) (shock hazard).
• Do not let the burner flame extend beyond the edge of
the pan (burn hazard on handles and potential cookware
damage / scorching).
• Turn off all controls when not cooking.
Failure to follow these instruction can result in personal injury
or fire.
Burners with two flame rings
These burners have two separate flame rings to provide a
complete heat regulation from high power to simmering.
To set :
1. Push and turn the knob counter clockwise within the main
HI - LO range, when the burner is turned on, the main flame
and the simmer flame will both ignite and remain on.
2. Set desired temperature within the main HI - LO range.
Note: The knob has a designated stop at MED heat setting. To
continue to low and / or simmer, push the knob in as
you continue to turn counter-clockwise. This method is
not required to go from LO / Simmer to OFF.
Simmer setting
Continue turning the knob counter-clockwise to the ‘HI-
LO SIMMER’ range. The outer flame ring will go out and
temperature adjustment can be made using the inner flame
ring only.
Turning off the burner
Turn the knob clockwise as far as it will go to the off position.
Ensure flame extinguishes fully.
KNOB BURNER
