12 - Replacing an Oven Light
• Each oven is equipped with three halogen lights located in
the lateral walls of the oven.
• The lights are switched on when the door is opened or
when the oven is in a cooking cycle.
• Each light assembly consists of a removable lens, a light
bulb as well as a light socket housing that is fixed in place.
See figure on this page.
• Light bulb replacement is considered to be a routine
maintenance item.
To Replace a Light Bulb
1. Read WARNING on this page.
2. Turn off power at the main power supply (fuse or breaker
box).
3. Remove the lens between screw and glass using a screw
driver.
4. Remove the light bulb from its socket by pulling it.
5. Replace the bulb with a new one. Avoid touching the bulb
with fingers, as oils from hands can damage the bulb when
it becomes hot.
6. The bulb is halogen: use one with the same type checking
Voltage and Wattage.
7. Place the lens back on.
8. Replace the rack supports if provided is provided with the
oven model.
Turn power back on at the main power supply (fuse or breaker
box).
WARNING
• Make sure the oven and lights are cool and power to
the oven has been turned off before replacing the light
bulb(s). Failure to do so could result in electrical shock
or burns.
• The lenses must be in place when using the oven.
• The lenses serve to protect the light bulb from breaking.
• The lenses are made of glass. Handle carefully to avoid
breakage. Broken glass could cause an injury.
OVEN LIGHT
