18 Reversing Door
A) Removing Latch Cover and Hole Plugs
1. Open the door.
2. Remove plastic hole plugs and save to
reinstall later. You may have to use a nan-
scratching plastic knife if you are unable
to dislodge the plugs manually.
B) Removing Door Assembly
1. Completely open the door to expose all
four hinge screws.
2. Remove all four hinge screws with #2
square bit driver. Save for reinstalling later.
3. Remove both screws from door latch
cover. Save latch cover and screws for
reinstallation later.
WARNING
ELECTRICAL SHOCK HAZARD
Failure to disconnect power source before
servicing could result in personal injury or
even death.
IMPORTANT
BEFORE YOU REVERSE YOUR DRYER DOOR:
1. Be sure you have adequate swing area
before reversing door.
2. Gather your tools - including a screw
driver with a #2 square bit and plastic
knife (or small, fl at prying tool that won’t
damage paint).
3. Be sure dryer is unplugged from power
source!
x 2
x 4
x 2
3. Grasp the door with both hands and lift
slightly as you pull door and hinge away
from the front panel.
Screwdriver
with #2
square bit
Tools needed for reversal:
Plastic
knife
NOTE
Door reversibility is available on the following dryer models: 300, 400, 500, or 600 series.
