7
5. Push the brackets firmly onto each side of the cooktop
cutout and wait 1 hour for adhesive to dry.
To Install Brackets into Wood Countertop:
1. Measure the center line of the vertical sides of the cooktop
cutout.
2. Position brackets in the center of the vertical centerline and
align the upper edge of the brackets so that they ar e flush
with the countertop.
3. Attach the brackets in the cutout with the screws provided.
Install Cooktop
1. Using 2 or more people, place the cooktop upside down
on a covered surface using the foam end posts from the
packaging.
2. Optional - Remove the foam roll from the package containing
literature. Apply foam adhesive-side down around the
bottom of the cooktop glass.
NOTE: The foam helps avoid damage to the underside of the
cooktop glass fr om debris and helps the cooktop sit flat on
uneven counters.
3. Lower the cooktop into the cutout with the back end of the
cooktop angled down.
4. Make sure that the clips on each side of the cooktop line up
with the brackets in the cutout.
5. Push down on cooktop to snap the cooktop clips onto the
brackets installed in the cutout.
Center line
A
B
A. Bracket
B. Screw
WARNING
Excessive Weight Hazard
Use two or more people to move and install cooktop.
Failure to do so can result in back or other injury.
A
B
C
A. Cooktop base
B. Foam
C. Assembly glass
Front side
A
A. Clip
A
B
A. Induction cooktop
B. Cooktop cutout
